DC FUSE PANEL LAYOUT
Below is a typical wiring layout. Your individual trailer may be different.
# Size Function
1 20 amp breaker Amplifier/Bed Lift
2 15 amp fuse Bathroom Lights & Vent
3 15 amp fuse Monitor Panel/Holding Tanks/Water Pump/Water Heater/Sink Lights
4 15 amp fuse Refrigerator/Furnace
5 15 amp fuse Bedroom Lights
6 15 amp fuse Amplifier Switch/Propane Detector/TV Outlet/Radio
7 15 amp fuse Porch/Entry/Main Living Area Lights
8 15 amp fuse Bunk/Rear Ceiling Lights
9 15 amp fuse Fuel Gauge/Bed Lift Switches
10 15 amp fuse Security Lights
11 15 amp fuse Ramp Lights
12 20 amp breaker Fuel Station
CIRCUIT BREAKERS
The following table provides generic circuit breaker alignment information. Your RV may not be exactly
the same as shown depending on the model, floor plan and options.
Main 30-amp main, incoming power to unit
A 15-amp microwave
B 15-amp refrigerator/GFCI (kitchen/bath)
C 20-amp air conditioner
D 15-amp utility/converter
E 15-amp water heater
PROPANE CONSUMPTION CHART
The following chart provides an average propane consumption information.
Appliance
Approximate BTU Consumption
Per Hour
Approximate
Kilojoules Per Hour
Water Heater 12,000 12,660
Refrigerator 1,500 1585
Furnace 25,000 26,375
Range w/ Oven 29,100 30,700
Slide-in Cooktop - 3 burner 22,000 23,200
93
SECTION 12
SPECIFICATIONS & GLOSSARY
