SECTION 5
ELECTRICAL SYSTEM – 30 AMP TOWABLE
5 - 6
BATTERY ISOLATOR FOR YOUR TOW
VEHICLE (CUSTOMER SUPPLIED)
5.
Insert a new fuse of t
he same s
pecified
voltage, amperage rating and type in the
original location. Never use a higher
rated replacement fuse.
You may want to consider the installation of a
battery isolator on your tow vehicle as a
convenience feature:
The fuse panel label should
be kept
permanently affixed to y
our RV. The fuses will
not offer complete protection of the RV
electrical system in the event of a power
surge or spike.
□ It receives current fro
m the tow vehicle
alternator and controls distribution of
energy to both the RV auxiliary battery
and the tow vehicle battery.
□ It serves as a check valve to prevent
energy fro
m being drawn from your tow
vehicle chassis battery (so you can start
your tow vehicle engine).
12-VOLT DC OUTLET
(I
F SO EQUIPPED)
There may be a 12-volt DC outlet (not
applicable on all models) in your RV. When
the 12-volt DC outlet is used as a power
source for an electric appliance, make sure
that the appliance operates on 12-volt DC
power and that it consumes less than 60
watts (5 amps) of 12-volt power. To prevent
short circuits do not allow metallic foreign
matter to get into the 12-volt DC outlet.
Your dealer can assist
you with the selection,
purchase a
nd installation of this aftermarket
part.
12-VOLT FUSE PANEL
The 12-volt fuse panel is labeled to indicate
fuse sizes, positions and the components
powered. At the beginning of camping
season, inspect all the 12-volt fuses and
replace as needed.
Replacing a fuse
Replacement fuses must be of the same
voltage, amperage rating and type. Never
use a higher rated replacement fuse; doing
so may cause a fire by overheating the RV
wiring.
Before replacing a
fuse, always turn “off” the
electrical component(s) protected by it.
1. Disconnect the shore power cord.
2. Disconnect the RV auxiliary battery main
negative battery cable.
3. Remove the fuse panel cover to check
fuses.
4. Pull the fuse straight out of the fuse block.
If the fuse is not blown, something else
must be causing the problem. Please
contact your dealer for further assistance.
