SECTION 12
TOWABLE SPECIFICATIONS
12 - 3
DC FUSE PANEL LAYOUT
Below is a typical wiring layout. Your individual trailer may be different.
# Size Function
1 — Open
2 15 amp fuse Bathroom Lights & Vent
3 15 amp fuse Pump/Monitor Panel/Range Hood/Sink Lights
4 15 amp fuse Refrigerator/Furnace
5 15 amp fuse Bedroom
6 15 amp fuse TV/Radio/Propane Detector
7 15 amp fuse Ceiling Lights
8 15 amp fuse Bunk Lights
9 15 amp fuse Slideout Lights
10 15 amp fuse Option
11 15 amp fuse Option
12 20 amp auto Slideout Motor
CIRCUIT BREAKERS
The following table provides generic circuit breaker alignment information. Your RV may not be
exactly the same as shown depending on model, floor plan and options.
Main 30 amp Main, Incoming Power to Unit
A 15 amp Microwave
B 15 amp Refrigerator/GFCI (Kitchen/Bath)
C 20 amp A/C
D 15 amp Utility/Converter
E 15 amp Water Heater
