Jayco 2016 White Hawk - ABS Plastics; Storing the Murphy Bed

SECTION 12-INTERIOR JAYCO TOWABLE TABLE OF CONTENTS
12-8
Storing the Murphy bed:
 Attach the “Y” strap that holds the mattress to the bedframe. Pull the straps with the
buckles up from the head of the bed and snap them to the “Y” strap. Secure the snap
hook at the footboard.
MAKE SURE THE SAFETY STRAPS AT EACH SIDE OF THE
FOOTBOARD ARE STILL ATTACHED TO THE STEEL LOOPS ON THE
SOFA ARMS BEFORE PUTTING ANY WEIGHT ON THE BED.
 Unhook the safety strap snap hooks from the steel loops on the arms of the sofa.
 Push the bed back up into the storage position.
 Secure the two “D” bolts on each side of the bed
 Flip the sofa back up into the seated position:
o Firmly grasp the edge of the top cushion and the front edge of the seat cushion.
o Push the cushions down and towards each other so they form a “V” shape.
o While holding the cushions in this “V” shape, rotate the sofa back towards the
wall and the cushions will revert back to the seated position.
ABS PLASTICS
Dust and wipe clean with soft, damp cloth or chamois, wiping gently. Do not use gritty or
abrasive particle soaps or scouring compound to clean ABS plastic. Avoid using “citrus”
or biodegradable cleaners which contain “D-Limonene” as they may damage plastic
materials.
WARNING
Keep hands and fingers away from the collapsing footboard and struts when pushing
the bed back in to the storage position.
