JAYCO TOWABLE SECTION 5 – SLIDE-OUT SYSTEMS
5-9
3. Release the switch, which will lock the room into position. If the slideout switch is
held after the room is fully extended, the control will sense that the room has stopped
and will shut the motor off after a few seconds.
4. Install the transit bars (if so equipped).
Manual Operation for the Power Gear slideout system
Your slideout system is equipped with a manual override that allows you to extend or
retract the room in the event of a loss of power.
NOTE if the room does not move when the switch is pressed, check the following:
 Make sure the slideout system is turned on.
 Battery is fully charged and connected.
 Transit bars have been removed (if so equipped).
When these items have been checked and the room still does not move when the switch is
pressed, follow the steps below to manually override the slideout room.
1. Turn the Main Power OFF. The override will not work if it has power going to it.
Do not work on the system unless the battery is disconnected.
2. Locate the slideout controller. There are two versions of the controller.
Version 1, unplug the 6 pin wiring harness from the controller.
Version 2, remove one of the motor leads, either the motor I or motor II lead
from the controller.
3. Locate the slideout motor (Fig. 1). It will be mounted to one of the slideout rails. If
the RV has an underbelly or cover over the motor, these parts will need to be
removed to access the motor. In a bedroom slideout, it may be located under the
bed.
CAUTION
Always disconnect battery from system prior to manually operating system. Failure to
disconnect battery can cause electricity to backfeed through the motor and cause
serious damage to the system as well as void the warranty
CAUTION
The gears can be stripped out if the room is manually retracted/extended to its fullest
extent and the operator continues to rotate manual override. Any damage due to
misuse of the Manual Override feature will disqualify any and all claims to the
Limited Warranty.
WARNING
When the motor brake is disengaged the slideout room WILL NOT lock into place;
therefore, the room will not be sealed. When the room has been manually retracted,
be sure to install the transit bars (if so equipped) and return the motor brake lever to
its normal engaged position in order to seal and lock the room into position.
