50-amp Service Option
A 50-amp service is available as an option. Below is a generic drawing with circuit breaker
alignment.
The Systems 37
20
20
15
15
15 15
15
15
50 50
AB
C
D
E
FG
H
Refer to 12-volt DC
system for this layout
Fig. 4-27
A = 15-amp microwave oven
B = 20-amp air conditioner
C = 15-amp refrigerator & utility
D = 15-amp GFCI and kitchen circuits
E = 15-amp water heater
F = 15-amp washer
G = 15-amp dryer
H = 20-amp air conditioner
To Next Page
