Closing Camper for Travel
INSIDE
1. Enter camper and remove canvas from screen door by pulling canvas away from
channel, beginning at the TOP of door, proceeding to bottom.
2. Disengage barrel locks. Unscrew plastic screws and remove door from top track.
Remove door from bottom track and slide door to travel position and lock in place
with turn button located on bottom of door by turning 1/4 turn. Snap ties holding
door to roof.
3. Zip all windows closed.
4. Roll all privacy drapes to the ceiling by pressing both buttons on either side of the
black locks and drawing the locks upward.
5. Remove bow braces from bracket on the roof and pull brace to center of coach.
Remove from peg on bed bow. Place bows under bed mattress. Fig. 5
6. Slide wardrobe toward aisle and lower to aisleway.
7. Flip dinette seat over.
8. Raise non-hinged side of flip top. Flip up leg.
9. Raise hinged side of flip top and slide leg to “down” position.
10. Flip over flip top.
CAUTION: Failure to properly position the kitchen flip top for travel can result in
roof damage and prevent the roof from lowering properly.
11. Remove all soft storage compartments.
Fig. 3-7
