Fuse and Bulb Chart
FUSES:
Circuit
Operation Location Number Fuse Size Type
Interior Lights/Water Pump in convertor 1 15 Blade
Furnace in convertor 3 15 Blade
Refrigerator in convertor 2 15 Blade
Battery Pac in line by battery 4 20 Blade
LP Detector Behind LP N/A 1 Blade
Some components listed above are options.
BULBS:
Interior . . . . . . . . . . . Ceiling, Bunk Lights . . . . . . . . #921
Exterior . . . . . . . . . . Porch Light . . . . . . . . . . . . . . . #912
Exterior . . . . . . . . . . Tail Light / Signal . . . . . . . . . #1157
Exterior . . . . . . . . . . Clearance . . . . . . . . . . . . . . . . #194
Interior. . . . . . . . . . . Courtesy . . . . . . . . . . . . . . . . . TY67
WARNING: Do not replace circuit breakers or fuses with a higher current
rating than those supplied with the new camper. Over-fusing can cause a fire
hazard by overheating the electrical wiring.
When attaching wire leads to a tow vehicle, carefully insulate all connections for
protection. Follow the instructions on instruction sheet provided with covered harness.
