57
Motors and cables are behind the interior fascia board around the slideout opening.
Cables may stretch over time. Average stretch will be approximately 1/8” but it
will not aect the function and does not require adjustment.
Slideout runs o the DC power in the RV.
Rubber wipes prevent debris from entering the unit and actuation guides the bulb
seals to close tightly.
Self-locking motor freezes the room in any position of travel.
Slideout is supported by rollers or wear bars not the cables. Cables are used to
keep the slideout balanced on the rollers.
generally there is no 12V power to the drive motor. The mo-
tor is equipped with a hex drive override shaft. This drive can be activated using an electric
drill and the exible shaft provided with each unit (or use a ratchet to actuate the motor) to
pull the room in or out.
1. Locate the included exible shaft in your owner’s packet.
2. Attach exible shaft to the 1/4” hex tting on the end of the motor.
3. Attach 1/4” socket & ratchet, or drill to the other end, and turn in the proper direction
to move the room.
4. If the cables tighten, and the motor is dicult to turn, REVERSE THE DIRECTION.
- The slideout system is equipped with a manual override that allows you
to extend or retract the room in the event of a loss of power.
Make sure the slideout system is turned on.
Battery is fully charged and connected.
Transit bars have been removed (if so equipped).
Always disconnect battery from system prior to manually operating
system. Failure to disconnect battery can cause electricity to back feed
through the motor and cause serious damage to the system as well as void
the warranty.
The gears can be stripped out if the
room is manually retracted/extended to its fullest extent and the operator
continues to rotate manual override. Damage can also occur to the slide
components, slide room structure or trim components. Damages due to
misuse of the manual override feature will void any and all claims to the
Limited Warranty.
When the motor brake is disengaged the slideout room WILL NOT lock into
place and will not be sealed. When the room has been manually retracted, be
sure to install transit bars (if so equipped) and return the motor brake lever to
its normal engaged position in order to seal and lock the room into position.
