1. Locate the slideout system controller.
2. Unplug motor 1 and motor 2 connectors at the bottom of the slideout controller. This
releases the motor brakes for each motor.
3. The slideout room can now be manually pushed in. Larger rooms may require several
people to push or pull them.
4. Keep both sides of the slideout relatively even while pushing/pulling.
5. When the room is completely in, plug both motor connectors back into the control
module. This will apply the motor brakes for road travel.
1. Locate and remove the motor retention screw, which can be found near the top of each
vertical column (.
2. Bend back the wipe seal and visually locate the motor ().
3. Pull the motor up until it disengages (about 1/2 inch).
4. Repeat this process for both sides of the slide room.
5. Physically push/ pull the room back into the opening; keep both sides relatively even.
6. The room must be travel locked to keep the room in place for road travel.
When an error code occurs during operation, the board LEDs lights will indicate where the
problem is. For motor specic faults the green LED will blink (1) time for motor #1 and (2)
times for motor #2. The red LED will blink 2 to 9 times depending on the error code. Error
codes are as follows:
2 times enough to drop below 6 volts while running.
3 times is below 8 volts at the start of a cycle.
4 times is greater than 18 volts.
5 times (high amperage) also indicated by (1) side
of the slide continually stalling.
6 times motor or wiring to motor has shorted out.
8 times : encoder not providing a signal; usually a
wiring problem.
9 times power to encoder has been shorted to
ground; usually a wiring problem.
The board will need to be reset after an error code. Energizing the extend / retract switch will
reset the board; energizing it a second time will return it to normal operation.
Refer to the Schwintek Slide Room Operation Guide for additional troubleshooting informa-
tion, or contact Lippert at (866) 524–7821 or at www.lci1.com.
The Norco slideout system is a cable driven slide out used typically on towable products.
The cables guide the room in or out, while the Accu-Slide mechanism evenly pow-
ers the corners keeping the room square.
