OEM WHEEL LUG TORQUE CHART
Wheel Torque Requirements
Lug Nut Rim Type Stage 1 Stage2 Stage 3
4-Lug Nuts 12" Steel 20-25 ft/lbs 35-40 ft/lbs 50-75 ft/lbs
5-Lug Nuts 13" Steel 20-25 ft/lbs 35-40 ft/lbs 50-75 ft/lbs
5-Lug Nuts 13" Chrome 20-25 ft/lbs 35-40 ft/lbs 50-75 ft/lbs
5-Lug Nuts 14" Steel 20-25 ft/lbs 50-60 ft/lbs 90-120 ft/lbs
5-Lug Nuts 14" Chrome 20-25 ft/lbs 50-60 ft/lbs 90-120 ft/lbs
5-Lug Nuts 14" Aluminum 20-25 ft/lbs 50-60 ft/lbs 90-120 ft/lbs
5-Lug Nuts 15" Chrome 20-25 ft/lbs 50-60 ft/lbs 90-120 ft/lbs
6-Lug Nuts 15" Steel 20-25 ft/lbs 50-60 ft/lbs 90-120 ft/lbs
6-Lug Nuts 15" Aluminum 20-25 ft/lbs 50-60 ft/lbs 90-120 ft/lbs
6-Lug Nuts 15" Chrome 20-25 ft/lbs 50-60 ft/lbs 90-120 ft/lbs
6-Lug Nuts 16" Steel 20-25 ft/lbs 50-60 ft/lbs 90-120 ft/lbs
6-Lug Nuts 16" Chrome 20-25 ft/lbs 50-60 ft/lbs 90-120 ft/lbs
8-Lug Nuts 16" Steel 20-25 ft/lbs 70-80 ft/lbs 110-130 ft/lbs
8-Lug Nuts 16" Aluminum 20-25 ft/lbs 70-80 ft/lbs 110-130 ft/lbs
A torque wrench is the best way to assure the proper amount of torque is being applied. Also review the axle
manufacturer’s operation and service manual supplied with your trailer or contact your independent, authorized dealer
for further assistance.
DC FUSE PANEL LAYOUT
Below is a typical wiring layout. Your individual trailer may be different.
Fuses
Operation Location
Circuit
Number
Fuse
Size
Type
Interior Lights, Water Pump, Radio In converter 1 15 Blade
Refrigerator In converter 2 15 Blade
Furnace In converter 3 15 Blade
Battery Charge In converter 4 15/20/30* Blade
Battery Prep In line by battery -- 30 Blade
Propane Detector Behind propane Detector N/A 1 Blade
*15-amp with 12-amp converter
*20-amp with 20-amp converter
*30-amp with 30-amp converter
