38
The following is an overview of the system to be used as a quick reference.
Depend-
ing on your model, the system may vary slightly from the following instructions. Familiar-
ize yourself with the operating and safety instructions prior to using the leveling system.
Prior to operation, make sure the following conditions are met:
The recreation vehicle is parked on a reasonably level
surface. EXCESS ANGLE will appear on the LCD dis-
play if the coach is 3.5° out of level front to rear or side
to side. Refer to error modes in the OEM operating
manual in your warranty packet.
All pets, persons and property are clear of the unit while
in operation.
Battery should be fully charged or unit plugged into shore power.
scrolls up through the menu on LCD
scrolls down through the menu on LCD
activates modes and procedures indicated on LCD
places leveling system into retract mode. Manual Mode ONLY. Press and
hold down for (1) second to initiate auto retract.
displays procedures and results
places leveling system into auto level mode
activates both front jacks in manual mode
activates left leveling jack(s) in manual mode
activates right leveling jack(s) in manual mode
activates both rear jacks in manual mode
. Lifting
the RV so the wheels are not touching the ground will create an unstable
and unsafe condition and may result in serious personal injury or death.
The leveling system is designed only for leveling the unit and should
never be used to provide service for any reason under the recreation vehi-
cle such as changing tires or servicing the system. It is not recommended
that you change a tire yourself.
Ensure all jack locations are clear of debris, obstructions or depressions.
When parking the RV on extremely soft surfaces, utilize the load distri-
bution pads under each jack.
People and pets should be clear of the coach while operating the leveling
system.
Keep hands and other body parts clear of uid leaks. Oil leaks may be
under high pressure and can cause serious skin penetrating injuries.
The use of the electronic automatic leveling system to support the coach
for any reason other than which it is intended is prohibited and will vio-
late terms of the limited warranty.
