turns leveling system on and o
1. Begin with a manual leveling sequence to get the vehicle to the desired level point
2. Activate the Level Zero point conguration mode as follows:
○ Turn the panel OFF.
○ Press the FRONT switch 10 times.
○ Press the REAR switch 10 times.
○ A tone will sound and the display will read ZERO POINT CALIBRATION.
○ Press ENTER to set the zero point.
3. Screen will display Zero Point Stability Check and PLEASE WAIT.
4. Tone will sound and the screen will display ZERO POINT SUCCESSFUL.
5. Control will turn OFF.
The leveling control will automatically detect an air bag system.
If the unit does not use air bags, the display will read “NO” for air bag control.
If the display reads “NO” but an air bag system is present on the unit:
1. Conrm harness is connected properly.
2. Run Auto-Level function.
3. Recalibrate the Zero Point.
4. If the air bag system is still not being detected, contact the OEM for further informa-
tion.
If the alarm system detects that the park brake has been disengaged while at least one jack is
not fully retracted and the sensor value changes in any axis more than a predened amount,
the panel will signal an error.
When in alarm mode, all LEDs will ash and buzzer will beep. The Status LEDs will show
the system status.
The system performs an automatic retract. No other features are available in this mode.
○ The system automatically shuts down after (4) minutes of no operation. To reset
the system, the coach ignition be turn o, then back on, and the power
button on the Control Panel be pressed again.
○ Auto leveling cycle cannot be started until all jacks are fully retracted. Verify
jacks are retracted before attempting to auto level. (Unit will perform a full
retract automatically if jacks are down on the request of an auto cycle.)
○ System will refuse any operation when a low voltage condition is present.
○ System will automatically alarm and retract if the park brake is disengaged and
jacks are not retracted with any change in sensor readings. In alarm mode, the
only available feature is to retract all jacks.
Note WAIT display shows the status of Air/Auxiliary features.
