1. The vehicle requires 12.7V DC to operate in the AUTO mode. If voltage is too low,
screen displays LOW VOLTAGE. If voltage drops below 12.7V DC, the system will
only operate in MANUAL MODE and continues to display LOW VOLTAGE.
2. Minimum Voltage – If voltage drops below 9.5 V DC during AUTO or MANUAL op-
eration LOW VOLTAGE will appear on display and system stops operating.
1. Push power button (right corner). System is operational and electronic level lights
become active.
2. Check that the Control Pad ENGAGE PARKING BRAKE is engaged.
3. Press the AUTO LEVEL button to begin the automatic leveling cycle.
4. Push the power button to de-energize the system.
1. Press power button on control panel. System is operational and power light will be lit.
2. Press DOWN ARROW to display MANUAL LEVEL on the display. Press ENTER
to set.
3. Press FRONT button until jacks contact the ground and lift front of the coach 1 to 2
inches.
4. Press REAR button until jacks contact the ground and lift the rear of the coach. Keep
the button depressed until the level indicator displays level.
5. Press LEFT or RIGHT button. If level indicator is toward left of coach, press RIGHT
button. If level indicator is toward right of the coach press LEFT button. Keep the
button depressed until level indicator displays level.
6. Repeat steps 2 through 5 if needed.
7. Turn power o to the leveling system by pressing the power button.
8. Visually inspect all jacks to ensure all shoes are touching the ground. If one of the rear
jack shoes not touch the ground, press the corresponding LEFT or RIGHT button to
lower the non-compliant jack to the ground.
Failure to act in accordance with the following warning may result in serious
personal injury or death!
WHEELS MUST LEAVE THE GROUND DURING LEVELING
OF THE RV.
