JB Systems CMX 24 User Manual

CMX 24 5
15. FULL ON KEY
Activates the maximum output level of all channels and
disables BLACK OUT.
16. AUDIO LEVEL Slider
Adjusts the sensitivity of the audio signal.
17. BLACK OUT ey
18. STEP key
Press it once to move the program one step further.
19. AUDIO key
Press this key to go to audio control.
20. HOLD key
Press and hold the key and all output levels will remain the
same.
21. PARK
This key allows you to select SINGLE CHASE or MIX CHASE (in
CHASE//SCENES mode).
22. REC EXIT
When the Led lights up, KILL Mode is activated. When you
press a Flash key, all output levels will go to ‘0’ except the
selected channel.
23. RECORD key
Press this key to record the step in the program.
24. PAGE key
Press this key to select a Scene program in a certain page.
25. MODE SELECT
This key allows you to select CHASE//SCENES, Double Preset
or Single Preset.
26. DARK key
Press this key to pause the whole output, including Full On and
Flash.
27. ALL REV
This key allows you to change the direction of all Scene
programs.
28. 0% or 0-255 key
