Specifications
DDE
2-Tool Control Unit
Ref.: DDE-9C 100V 50/60Hz. Input fuse: T5A. Output: 23.5V
Ref.: DDE-1C 120V 50/60Hz. Input fuse: T4A. Output: 23.5V
Ref.: DDE-2C 230V 50/60Hz. Input fuse: T2A. Output: 23.5V
- Output Peak Power: 150W per tool
- Temperature Range: 90 - 450 °C / 190 - 840 °F
- Idle Temp. Stability (still air): ±1.5ºC / ±3ºF / Meets and exceed IPC J-STD-001F
- Temp Accuracy: ±3% (using reference cartridge)
- Temp Adjustment: ±50ºC / ±90ºF Through station menu setting
- Tip to Ground Voltage/Resistance: Meets and exceed
ANSI/ESD S20.20-2014 IPC J-STD-001F
- Ambient Operating Temp: 10 - 50 ºC / 50 - 122 ºF
- Connections: USB-A / USB-B / Peripherals connectors
RJ12 connector for Robot
- Control Unit Dimensions/Weight: 148 x 232 x 120 mm / 3.82 kg
(L x W x H) 5.8 x 9.1 x 4.7 in / 8.41 lb
- Total Package: 258 x 328 x 208 mm / 4.3 kg
10.15 x 12.9 x 8.1 in / 9.5 lb
Complies with CE standards.
ESD safe.
