Operation
JBC’s Most Efficient Soldering System
Our revolutionary technology is able to recover tip temperature extremely quickly. It means the user
can work at a lower temperature and improve the soldering quality. The tip temperature is further
reduced thanks to the Sleep and Hibernation modes which increase up to 5 times the life of the tip.
3. Hibernation1. Work 2. Sleep
When the tool is lifted from the
stand the tip will heat up to the
selected Work temperature.
When the tool is in the stand, the
temperature falls to the preset
Sleep temperature.
After longer periods of inactivity,
the power is cut off and the tool
cools down to room temperature.
Long period
in the stand
Tool Settings:
· Work Temp.
Change Work temperature
from 90 to 450 ºC.
or steps of ±5 ºC / ºF
Tool Settings:
· Temp. Levels
Press , select Tool Settings
and activate the Temp.Levels
option.
or steps of ± 5 ºC / ºF.
Tool Settings:
· Sleep
Change Sleep temperature and
set Sleep delay from 0 to 9min
or no Sleep.
Tool Settings:
· Hibernation
Change Hibernation delay
from 0 to 60min or no
Hibernation.
