jbc DDE - Connection Example; DDE Unit Connections

Stand Cable
Ref. 0024227
Connection Example
DRS
Stand for
DR560
Desoldering
Iron
ADS
Stand for
T210 & T245
Handles
DR560
Desoldering Iron
T245
General
Purpose
Handle
DDE 2-Tool Control Unit
Module Cable
Ref. 0024228
Stand Cable
Ref. 0024227
MSE
Electric Desoldering
Module for DDE & DME
Suction
Filter
Ref. 0821830
To another Peripheral
To Pedal P005
RJ12 connector
USB-B
connector
Equipotential
connector
Power Socket
3
