jbc DIU - Specifications

Specifications
DIU
1-Tool Control Unit
DI-1D 120V 50/60Hz. Input fuse: T2A. Output: 23.5V.
DI-2D 230V 50/60Hz. Input fuse: T1A. Output: 23.5V.
DI-9D 100V 50/60Hz. Input fuse: T2.5A. Output: 23.5V.
- Output Peak Power CD-BE: 130W
- Temperature Range: 90 - 450 °C / 190 - 840 °F (±5%)
- Idle Temp. Stability (still air): ±1.5 ºC / ±3 ºF
- Tip to Ground Voltage/Resistance: Meets and exceed
ANSI/ESD S20.20-2014 IPC J-STD-001F
- Ambient Operating Temp: 10 - 40 ºC / 50 - 104 ºF
- Connections: USB-B / Peripherals connectors
- Control Unit Dimensions / Weight: 180 x 94 x 106 mm / 2.153 kg
(L x W x H) 7.10 x 3.70 x 4.17 in / 4.75 lb
- Total Package Dimensions / Weight: 220 x 213 x 160 mm / 2.5 kg
(L x W x H) 8.66 x 8.39 x 6.30 in / 5.51 lb
Complies with CE standards.
ESD safe.
11
40 mm
50 mm
60 mm
80 mm
100 mm
130 mm
130 mm
para manuales - color gris
200 mm
300 mm
