INSTALL SETUP
Your D09 / D09B / D09C / D09D / D09E Power Wheelchair will arrive carefully packaged in
a cardboard box.
Open the top of the box then turn the box on the side for easier pulling out the chair and
contents.
Total components as bellow:
1.
2.
To unfold the D09 / D09B / D09C / D09D / D09E, grasp the push bar and pull up while
holding down on the seat to unfold the chair and complete the assembly.
3.
14
Lithiun battery 2 pcs
Wheelchair
Charger with
power cables
Tools 3 PCS
Seat cushion
Joystick controller
Push down seat to unfold
Grasp push bar
Safety belt 1 PC
Photo 3. Wheelchair Carton Content
Photo 4. Unfold the chair into a seated position
To Next Page
