19
INSTRUCTION OF OPERATION
Photo 15. Manual Fold
Photo 16. Manual Unfold
Making sure all the attaching parting are fastened properly after any adjustment , repair
or maintenance, for avoiding any damage or injury.
The wheelchair with certain weight that requires correct way of lifting up to avoid injury.
While it is necessary to lift up for moving the wheelchair, it is strong suggested user get off
wheelchair first.
If user have to stay in wheelchair for lifting up and moving at the same time, make sure
safety is fully secured. Do not hold attaching part for lifting and moving wheelchair.
◎ Procedures for Wheelchair Folding
Hold top of backrest frame with one hand, the other hand lift up the locking control
rod at the back of back rest for unlocking.
Lift up the front of seat by hand for folding.
Push top of back rest and front end of seat together.
Fold footrest.
1.
2.
3.
4.
Unfold footrest first.
Hold the top of backrest with one hand, the other hand hold front end of seat.
Both hand push away till a “Click” sound heard for completely unfold the wheelchair.
◎ Procedure for Wheelchair Unfolding
1.
2.
3.
To Next Page
