JBL ATX SUB 100 - Page 6

PART NO. DESCRIPTION
QTY
REFERENCE
1 97 5 0 73 Complete AMP 230V 110W 1
2 101OTLX110W PCB ASS'Y AMP 1
3 101ATLX110W AI PCB ASS'Y 1
4 104tlx11000 PCB 1
5 11012472j52
RESISTOR 4.7K 1/2W ±5% CF
2
R201,2
6 11014560j26
RESISTOR 56 1/4W ±5% CF
1
R117
7 11016101j26
RESISTOR 100 1/6W ±5% CF
1
R120
8 11016102j26
RESISTOR 1K 1/6W ±5% CF
6
R124,66,213,4,5,54
9 11016103j26
RESISTOR 10K 1/6W ±5% CF
17
R133,4,209,16,7,20,1,5
,6,8,32,5,48,60,212,22,40
10 11016104j26
RESISTOR 100K 1/6W ±5% CF
4
R163,4,231,66
11 11016105j26
RESISTOR 1M 1/6W ±5% CF
2
R143,259
12 11016123j26
RESISTOR 12K 1/6W ±5% CF
3
R135,9,65
13 11016124j26
RESISTOR 120K 1/6W ±5% CF
1
R233
14 11016151j26
RESISTOR 150 1/6W ±5% CF
1
R253
15 11016152j26
RESISTOR 1.5K 1/6W ±5% CF
7
R103,23,36,7,41,2,53
16 11016153j26
RESISTOR 15K 1/6W ±5% CF
5
R118,45,52,4,234
17 11016154j26
RESISTOR 150K 1/6W ±5% CF
6
R131,203,4,5,6,52
18 11016181j26
RESISTOR 180 1/6W ±5% CF
2
R111,4
19 11016183j26
RESISTOR 18K 1/6W ±5% CF
2
R227,62
20 11016205j26
RESISTOR 2.0M 1/6W ±5% CF
1
R257
21 11016223j26
RESISTOR 22K 1/6W ±5% CF
9
R128,9,55,6,8,
60,238,47,55
22 11016273j26
RESISTOR 27K 1/6W ±5% CF
2
R223,37
23 11016332j26
RESISTOR 3.3K 1/6W ±5% CF
3
R106,7,44
24 11016392j26
RESISTOR 3.9K 1/6W ±5% CF
2
R105,8
25 11016393j26
RESISTOR 39K 1/6W ±5% CF
1
R126
26 11016470j26
RESISTOR 47 1/6W ±5% CF
4
R112,3,5,6
27 11016471j26
RESISTOR 470 1/6W ±5% CF
3
R140,61,2
28 11016472j26
RESISTOR 4.7K 1/6W ±5% CF
10
R110,25,30,47,
50,7,9,200,7,58
29 11016473j26
RESISTOR 47K 1/6W ±5% CF
5
R101,219,49,50,1
30 11016512j26
RESISTOR 5.1K 1/6W ±5% CF
2
R210,1
31 11016513j26
RESISTOR 51K 1/6W ±5% CF
1
R224
32 11016563j26
RESISTOR 56K 1/6W ±5% CF
1
R104
SUB 100 PART LIST
