JBL ATX SUB 100 - Page 7

33 11016681j26
RESISTOR 680 1/6W ±5% CF
2
R148,51
34 11016682j26
RESISTOR 6.8K 1/6W ±5% CF
3
R109,229,30
35 1302b101k503
DISC CAPACITOR 100P 50V ±10%
3
C104,39,40
36 1302b102k503
DISC CAPACITOR 1000P 50V ±10%
2
C116,41
37 1302b221k503
DISC CAPACITOR 220P 50V ±10%
12
C204,5,7,8,10,1
,2,4,20,30,200,49
38 1302f104z503 DISC CAPACITOR 0.1U 50V +80/-20% 13
C108,13,5,9,37,8,
232,42,4,5,6,52,4
39 1303f473m503
DISC CAPACITOR 0.047U 50V ±20%
1
C106
40 130sl470k503 DISC CAPACITOR 47P 50V +350/-1000 1
C229
41 132103j503
MYLAY CAPACITOR 0.01U 50V ±5%
2
C223,4
42 132104j503
MYLAY CAPACITOR 0.1U 50V ±5%
4
C107,218,21,2
43 132223ja03
MYLAY CAPACITOR 0.022uF 100V ±
5%
9
C123,4,5,6,7,8,31,2,215
44 132473j503
MYLAY CAPACITOR 0.047U 50V ±5%
2
C216,7
45 1353105m50
ELECTROLYTIC CAP 1U 50V ±20%
3
C105,12,228
46 1353106m50
ELECTROLYTIC CAP 10U 50V ±
20%
10
C201,2,6,13,9,
31,41,3,51,3
47 1353107m16
ELECTROLYTIC CAP 100uF 16V ±
20%
5
C109,10,7,20,234
48 1353107m50
ELECTROLYTIC CAP 100U 50V ±
20%
2
C135,6
49 1353226m50
ELECTROLYTIC CAP 22U 50V ±20%
3
C114,8,225
50 1353227m10
ELECTROLYTIC CAP 220U 10V ±20%
2
C129,30
51 1353227m16
ELECTROLYTIC CAP 220U 16V ±
20%
1
C111
52 1353336m16
ELECTROLYTIC CAP 33U 16V ±20%
1
C233
53 1353476m25
ELECTROLYTIC CAP 47U 25V ±
20%
1
C103
54 192027c1815gr
TRANSISTOR 2SC1815GR
10
Q102,11,2,3,8,
23,6,201,6,7
55 192027c2235y
TRANSISTOR 2SC2235Y
1
Q121
56 192028a1015gr
TRANSISTOR 2SA1015GR
4
Q114,6,22,7
57 192028a965y TRANSISTOR 2SA965Y 1
Q125
58 1921672n5551 TRANSISTOR 2N5551 2
Q103,9
59 1921682n5401 TRANSISTOR
2N5401 AI-PNP 350V 500mA
2
Q104,10
60 197131n4148 1N4148 19
D101,3,5,8,13,4,201,
2,3,4,5,6,7,8,11,2,4,5,
61 19915000335 3.3V 1/2W 2
D102,213
62 19915000625 6.2V 1/2W 2
D106,7
63 19915001605 16V 1/2W 1
D109
64 101OTLX110WA PCB ASS'Y 1
65 101ATLX110WA AI ASS'Y 1
