JBL ATX SUB 100 - Page 8

66 104tlx1100a PCB 1
67 11016103j26
RESISTOR 10K 1/6W ±5% CF
9
R301,2,3,4,8,9,14,40,4
68 11016223j26
RESISTOR 22K 1/6W ±5% CF
2
R310,2
69 11016273j26
RESISTOR 27K 1/6W ±5% CF
1
R341
70 11016333j26
RESISTOR 33K 1/6W ±5% CF
1
R305
71 11016472j26
RESISTOR 4.7K 1/6W ±5% CF
2
R342,3
72 11016474j26
RESISTOR 470K 1/6W ±5% CF
1
R307
73 11016751j26
RESISTOR 750 1/6W ±5% CF
2
R311,3
74 11016755j26
RESISTOR 7.5M 1/6W ±5% CF
1
R306
75 1302f104z503 DISC CAPACITOR 0.1U 50V +80/-20% 2
C305,6
76 132103j503
MYLAY CAPACITOR 0.01U 50V ±5%
2
C302,3
77 1353226m50
ELECTROLYTIC CAP 22U 50V ±20%
2
C301,40
78 1353476m25
ELECTROLYTIC CAP 47U 25V ±20%
1
C304
79 192027c1815gr TRANSISTOR 2SC1815GR 2
Q301,2
80 197131n4148 1N4148 2
D301,2
81 1759f40hr2 40PIN PITCH=2.54mm HR2*40 0.13
P301
82 19016tl074cn I.C. TL074CN ST 1
U301
83 11010821jk1
RESISTOR 820 1W ±5%
1
R132
84 110122r2j15
RESISTOR 2.2 1/2W ±5%
1
R127
85 113500r1j10 CEMENT RESISTOR 0.1 5W 2
R121,2
86 11403302m0
SEMI-FIXED RESISTOR 3K 0.3W ±20%
1
R138
87 115h203b208 VARIABLE RESISTOR B20K 1
VR202
88 115h503a104 VARIABLE RESISTOR D16 50K/1 A 1
VR201
89 1354478m35
ELECTROLYTIC CAP 4700U 35V ±20%
2
C121,2
90 1354478m50
ELECTROLYTIC CAP 4700U 50V ±20%
2
C133,4
91 171udhss124d RELAY 5A 24V UDH-SS124D 1
RY101
92 1740300390g JACK 1
JK202
93 1742psz406g1 JACK S-8071 1
JK203
94 1742psz406g2 SPK JK 4PIN S-8072 1
JK203
95 180tms7210v SWITCH SLIDE 6PIN MS7210V 1
SW201
96 19006m4558d I.C. OPA 4558D 2
U101,203
97 19016tl074cn I.C. TL074CN ST 2
U201,2
98 192011d669a TRANSISTOR 2SD669A 1
Q106
99 192012b649a TRANSISTOR 2SB649A 1
Q105
100 192021c1815gr TRANSISTOR 2SC1815GR 2
Q101,15
101 192021tip35c TRANSISTOR TIP35C 1
Q107
