JBL Control One - Speaker Placement; Speaker Connections

ONE. Speaker Placement
As front speakers.
As rear speakers.
45°
1.5-1.8 m
TWO. Wall mounting
The Control ONE loudspeakers may be wall-mounted.
Please refer to wall-mounting instructions.
THREE. Speaker Connections
Speakers and electronics terminals have corresponding (+) and (-) terminals. It is important to
connect both speakers identically: (+) on the speaker to (+) on the amplifier and (-) on the
speaker to (-) on th amplifier. Wiring ‘out of phase’ results in thin sound, weak bass and a poor
stereo image.
– +– +
Front or Rear Speaker Outputs
LEFT RIGHT
LEFT
RIGHT
–
+
–
+
Front or Rear Channel Amplifier/Receiver Outputs
RIGHT LEFT
RIGHT LEFT
ConnectionsWires
