JBL CS300.1 Service Manual

Part Number Description Qty Reference Designator
220880242 Resistor RD 1/8W 2.4K 2 R24 R189
220880302 Resistor RD 1/8W 3K 5 R18 R38 R39 R150 R9
220880362 Resistor RD 1/8W 3.6K 2 R124 R187
220880363 Resistor RD 1/8W 36K 1 R50
220880392 Resistor RD 1/8W 3.9K 2 R129 R13
220880470 Resistor RD 1/8W 47Ω 2 R171 R172
220880472 Resistor RD 1/8W 4.7K 2 R173 R168
220880473 Resistor RD 1/8W 47K 5 R34 R102~R105
220880474 Resistor RD 1/8W 470K 2 R4 R128
220880562 Resistor RD 1/8W 5.6K 3 R120 R121 R125
220880563 Resistor RD 1/8W 56K 5 R106 R107 R108 R109 R51
220880682 Resistor RD 1/8W 6.8K 2 R16 R122
220880751 Resistor RD 1/8W 750Ω 1 R126
220880913 Resistor RD 1/8W 91K 2 R100 R101
230881001 Resistor MF 1/8W 1K 1% 1 R157
230881002 Resistor MF 1/8W 10K 1% 2 R19 R47
230881003 Resistor MF 1/8W 100K 1% 1 R114
230881052 Resistor MF 1/8W 10.5K 1% 1 R6
230882202 Resistor MF 1/8W 22K 1% 1 R8
230885601 Resistor MF 1/8W 5.6K 1% 1 R127
230886191 Resistor MF 1/8W 6.19K 1% 1 R170
202G15B23 VR B20K 2 VR101 VR103
202T15C52 VR C50K 1 VR102
231100100 Resistor 1Ws 10Ω 1 R31
231100220 Resistor 1Ws 22Ω 1 R37
23251002A Resistor SQM 5W 0.2Ω () 6 R180 R181 R182 R183 R184 R185
261T05103 Thermistor NTC THERMISTORD103J 10
K
1 RTH1
Capacitors
31J510110 Capacitor C/C NPO 100PF/100V J 5 C106 C107 C113 C114 C155
31K510210 Capacitor C/C 1000PF/100V K 2 C100 C101
31Z510305 Capacitor C/C Y5V 10000P/50V Z 1 C35
31Z510410 Capacitor C/C Y5V 0.1UF/100V Z 8 C6 C7 C8 C9 C10 C11 C31 C32
31J522010 Capacitor C/C NPO 22PF/100V J 1 C112
31J522110 Capacitor C/C NPO 220PF/100V 2 C12 C13
31J547010 Capacitor C/C NPO 47PF/100V J 3 C150 C151 C152
31K547110 Capacitor C/C Y5E470PF/100V K 1 C119
31K547310 Capacitor C/C 0.047UF/100V K 2 C38 C39
31J568125 Capacitor C/C Y5E 680P/250V K 1 C22
32J510410 Capacitor M/C 0.1UF/100V J 1 C157
32J518410 Capacitor M/C 0.18uf/100V J 1 C117
32J539310 Capacitor M/C 0.039UF/100V J 1 C118
32J568210 Capacitor M/C 0.0068uf/100V J 1 C20
32J582310 Capacitor M/C 0.082 UF/100V J 2 C115 C116
340Z10650 Capacitor 10UF/50V 5*11 3 C110 C111 C36
340Z10716 Capacitor 100U/16V 5*11 5 C4 C19 C27 C28 C156
340Z22550 Capacitor 2.2UF/50V 5*11 2 C33 C34
340Z22625 Capacitor 22UF/25V 5*11 8 C2 C103 C105 C21 C102 C104 C108 C109
340Z47550 Capacitor 4.7U/50V 5*11 1 C3
340Z47625 Capacitor 47UF/25V 5*11 3 C5 C14 C37
344Z22716 Capacitor 220UF/16V 6.3*12 2 C29 C30
370Z10550 Capacitor 1UF/50V 5*11 1 C154
370Z10716 Capacitor 100UF/16V 8*12 1 C18
370Z22616 Capacitor 22UF/16V NP 1 C1
391T10104 Capacitor (BOX) 0.1U/100V MEMB 1 C153
391T10474 Capacitor (BOX) 0.47U/100V J MEMB 2 C40 C41
341T22835 Capacitor 2200UF/35V 16*26 105C 3 C15 C16 C17
341T22863 Capacitor 2200UF/63V 22*27R 105C 4 C23 C24 C25 C26
CS Series 300.1
10
