Part Number Description Qty Reference Designator
Miscellaneous
571T20070 Wire 1015# 20AWG 70MM 1 GND
172T41026 Coil T23*90-26 1.2*5 2.6uH 1 L1
181T37621 Transformer 37φ6:21 F=1.2*3*6 S=1.2*2*21 1 T1
435T00020 Fuse 20A ATC 2 F1
447T00001 Fuse Holder PCB Fuse holder 1 F1
524TRC04S RCA Jack RCA Jack 1 RCA1
535T25002 Connector 2P P=2.5MM 9 1 J3
541T34304 Terminal HD-343 4Pin 3.4 1 J2
544T300003 Terminal GA30-03-3Pin 1 J1
137T05B02 LED 5ψLED Blue 3 BLED1~3
647CS3001 Heat sink CS300.1 L=300 1
674CS3001 Rear panel CS300.1 1
680CS3001 Front panel CS300.1 1
CS Series 300.1
11

Other manuals for JBL CS300.1

Preview: Owner's Manual
Owner's Manual8 pages

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the JBL CS300.1 and is the answer not in the manual?

JBL CS300.1 Specifications

CS300.1

Power IconPower
power at 4 ohms200W RMS x 1 channel
power at 2 ohms300W RMS x 1 channel
dynamic power at 2 ohms460W
Audio Performance IconAudio Performance
signal-to-noise ratio100dBA
frequency response10Hz – 300Hz
effective damping factor6.395 at 4 ohms
Input and Output IconInput and Output
maximum input signal6V
maximum sensitivity100mV
output regulation–0.07dB at 4 ohms
Weight and Dimensions IconWeight and Dimensions
dimensions (L x W x H)12-11/16" x 10-1/4" x 2-3/16"
fuses20A x 2
