APPLICATIONS – CS60.2
RightLeft
RightLeft
Figure 9. CS60.2 used in 2-channel (stereo)
operation to drive a set of full-range speakers.
Figure 10. CS60.2 used in bridge mode to drive a
subwoofer.
