JBL DCR600 - Electrical Parts List

DCR600 Electrical Parts List
REF. DESIGNATOR PART NUMBER PART NAME / DESCRIPTION Q'TY UNIT
DCR600 MAIN PCB
Capacitors
C421 13076940AM CE 470U0F +20% 63.0V 85C 1.000 PC
C422 13076940AM CE 470U0F +20% 63.0V 85C 1.000 PC
C423 13076940AM CE 470U0F +20% 63.0V 85C 1.000 PC
C424 13076940AM CE 470U0F +20% 63.0V 85C 1.000 PC
C481 J3420468266X CE 6800UF 63V 1.000 PC
C482 J3420468266X CE 6800UF 63V 1.000 PC
C485 J3470122261X CE 2200UP 35V 1.000 PC
C486 J3470122261X CE 2200UP 35V 1.000 PC
C487 J3420668236X CE SHL 6800U 16V M 1.000 PC
C488 J3470122231X CE 2200UF 16V 1.000 PC
C511 13076940AM CE 470U0F +20% 63.0V 85C 1.000 PC
C512 13076940AM CE 470U0F +20% 63.0V 85C 1.000 PC
C401 2026888030 CE 10U0F +20% 50.0V 85C 1.000 PC
C402 2026888030 CE 10U0F +20% 50.0V 85C 1.000 PC
C403 1105530071 CC 68P0F +5% -5% 50.0V NP0 1.000 PC
C404 1105530071 CC 68P0F +5% -5% 50.0V NP0 1.000 PC
C405 2026907030 CE 100U0F +20% 25.0V 85C 1.000 PC
C406 2026907030 CE 100U0F +20% 25.0V 85C 1.000 PC
C407 2026908030 CE 220U0F +20% 10.0V 85C 1.000 PC
C408 2026908030 CE 220U0F +20% 10.0V 85C 1.000 PC
C409 3093607071 CC 12P0F +5% -5% 50.0V NP0 1.000 PC
C410 3093607071 CC 12P0F +5% -5% 50.0V NP0 1.000 PC
C411 6043915071 CC 33P0F +5% -5% 50.0V NP0 1.000 PC
C412 6043915071 CC 33P0F +5% -5% 50.0V NP0 1.000 PC
C413 2026888030 CE 10U0F +20% 50.0V 85C 1.000 PC
C414 2026888030 CE 10U0F +20% 50.0V 85C 1.000 PC
C415 2026888030 CE 10U0F +20% 50.0V 85C 1.000 PC
C416 2026888030 CE 10U0F +20% 50.0V 85C 1.000 PC
C417 J3640104320X CP MET .1U 63V -K 1.000 PC
C418 J3640104320X CP MET .1U 63V -K 1.000 PC
C419 J3640104320X CP MET .1U 63V -K 1.000 PC
C420 J3640104320X CP MET .1U 63V -K 1.000 PC
C431 J3600473330X CP .047U 100V K 1.000 PC
C432 J3600473330X CP .047U 100V K 1.000 PC
C433 J3600473330X CP .047U 100V K 1.000 PC
C483 J3640104350X CP MET .1U 250V -M 1.000 PC
C484 J3600473330X CP .047U 100V K 1.000 PC
C489 2026888030 CE 10U0F +20% 50.0V 85C 1.000 PC
C490 2026888030 CE 10U0F +20% 50.0V 85C 1.000 PC
C492 2026888030 CE 10U0F +20% 50.0V 85C 1.000 PC
C494 2026888030 CE 10U0F +20% 50.0V 85C 1.000 PC
C496 2026888030 CE 10U0F +20% 50.0V 85C 1.000 PC
C497 2026888030 CE 10U0F +20% 50.0V 85C 1.000 PC
C498 2026888030 CE 10U0F +20% 50.0V 85C 1.000 PC
C501 2026888030 CE 10U0F +20% 50.0V 85C 1.000 PC
C502 1105530071 CC 68P0F +5% -5% 50.0V NP0 1.000 PC
C503 2026907030 CE 100U0F +20% 25.0V 85C 1.000 PC
C504 2026908030 CE 220U0F +20% 10.0V 85C 1.000 PC
C505 3093607071 CC 12P0F +5% -5% 50.0V NP0 1.000 PC
C506 6043915071 CC 33P0F +5% -5% 50.0V NP0 1.000 PC
C507 2026888030 CE 10U0F +20% 50.0V 85C 1.000 PC
C508 2026888030 CE 10U0F +20% 50.0V 85C 1.000 PC
C509 J3640104320X CP MET .1U 63V -K 1.000 PC
C510 J3640104320X CP MET .1U 63V -K 1.000 PC
C551 J3640683220X CMP 0.068U 63V J 1.000 PC
C552 J3640683220X CMP 0.068U 63V J 1.000 PC
C553 J3640683220X CMP 0.068U 63V J 1.000 PC
C554 J3470147121X CE SG 470U 10V M 1.000 PC
C555 7042852071 CC 10N0F +10% -10% 50.0V Y5P 1.000 PC
C556 7042852071 CC 10N0F +10% -10% 50.0V Y5P 1.000 PC
C564 J3640104350X CP MET .1U 250V -M 1.000 PC
C565 J3640104350X CP MET .1U 250V -M 1.000 PC
DCR600
39
