REF. DESIGNATOR PART NUMBER PART NAME / DESCRIPTION Q'TY UNIT
L501 J1451000030X COIL-AF CHOKE .7UH 1.000 PC
P551 J2431100002X POSISTOR PTC 1.000 PC
J60530002100 H/SINK REG 118*20*50H 1.000 PC
CN401 J4420050300X CNT ST 35313-0310 1.000 PC
CN402 J4420040600X CNT PLUG 2.5 6P 1.000 PC
CN403 J4420040300X CNT PLUG 2.5 3P 1.000 PC
CN407 J4423230500X CNT 2.0MM 35336-0510 PLUG BD'BD 1.000 PC
CN408 J4423231500X CNT 2.0 35336-1510 1.000 PC
CN409 J4423231500X CNT 2.0 35336-1510 1.000 PC
CN410 J4423231500X CNT 2.0 35336-1510 1.000 PC
CN411 J4423231500X CNT 2.0 35336-1510 1.000 PC
CN412 J4423231600X CONNECTOR 1.000 PC
CN413 J4423231100X CONNECTOR 1.000 PC
CN414 J4422112740X FPC PLUG 27P 1.25 1.000 PC
CN415 J4423231600X CONNECTOR 1.000 PC
CN416 J4420030640X CNT PLUG 2.0 6P ST 1.000 PC
CN417 J4420040300X CNT PLUG 2.5 3P 1.000 PC
CP404 J4305100067X CNT ASSY12P 390MM SL 2.0MM #28 1.000 PC
CP406 J4305100069X CNT ASSY 10P 390+520 #28 1.000 PC
FU481 J5502220320X FUSE 2A/125V 1.000 PC
FU482 J5502220320X FUSE 2A/125V 1.000 PC
FU483 J5502220320X FUSE 2A/125V 1.000 PC
FU484 J5502220320X FUSE 2A/125V 1.000 PC
G011 J4200020000X GND PLATE 1.000 PC
WA401 J4420040200X CNT ST 5267-02A 1.000 PC
WA402 J4420040200X CNT ST 5267-02A 1.000 PC
WA403 J4420040200X CNT ST 5267-02A 1.000 PC
W401 J4305100072X CNT ASSY 1P 250MM #18 1.000 PC
FH401 J4210020001X FUSE CLIP 0.3T 1.000 PC
FH402 J4210020001X FUSE CLIP 0.3T 1.000 PC
FH403 J4210020001X FUSE CLIP 0.3T 1.000 PC
FH404 J4210020001X FUSE CLIP 0.3T 1.000 PC
FH405 J4210020001X FUSE CLIP 0.3T 1.000 PC
FH406 J4210020001X FUSE CLIP 0.3T 1.000 PC
FH407 J4210020001X FUSE CLIP 0.3T 1.000 PC
FH408 J4210020001X FUSE CLIP 0.3T 1.000 PC
DCR600 FRONT PCB
Capacitors
7043654016 D-SLP 1N4148 100.0V 150E-3A 1.000 PC
C203 2026783030 CE 47U0F +20% 16.0V 85C 1.000 PC
C210 2026888030 CE 10U0F +20% 50.0V 85C 1.000 PC
C216 J3433247321X CAP GOLD 0.047F 5.5V SCDA5R5473H 1.000 PC
CL201 1500213030 CE 10U0F +20% 16.0V 85C 1.000 PC
CL202 3093623071 CC 100P0F +5% -5% 50.0V NP0 1.000 PC
CL203 8043459071 CC 22P0F +5% -5% 50.0V NP0 1.000 PC
CL204 1500213030 CE 10U0F +20% 16.0V 85C 1.000 PC
CL205 1500213030 CE 10U0F +20% 16.0V 85C 1.000 PC
CL206 J3640183232X CAP M POLY 18NF 100V J 1.000 PC
CL207 J3640823232X CAP M POLY 82NF 100V J 1.000 PC
CL208 J3640332232X CAP POLY 3N3F 100V J 1.000 PC
CL209 J3640183232X CAP M POLY 18NF 100V J 1.000 PC
CR201 1500213030 CE 10U0F +20% 16.0V 85C 1.000 PC
CR202 3093623071 CC 100P0F +5% -5% 50.0V NP0 1.000 PC
CR203 8043459071 CC 22P0F +5% -5% 50.0V NP0 1.000 PC
CR204 1500213030 CE 10U0F +20% 16.0V 85C 1.000 PC
CR205 1500213030 CE 10U0F +20% 16.0V 85C 1.000 PC
CR206 J3640183232X CAP M POLY 18NF 100V J 1.000 PC
CR207 J3640823232X CAP M POLY 82NF 100V J 1.000 PC
CR208 J3640332232X CAP POLY 3N3F 100V J 1.000 PC
CR209 J3640183232X CAP M POLY 18NF 100V J 1.000 PC
C201 2026783030 CE 47U0F +20% 16.0V 85C 1.000 PC
C202 2026783030 CE 47U0F +20% 16.0V 85C 1.000 PC
C204 2026901030 CE 47U0F +20% 50.0V 85C 1.000 PC
C214 2026783030 CE 47U0F +20% 16.0V 85C 1.000 PC
C215 2026783030 CE 47U0F +20% 16.0V 85C 1.000 PC
C219 2026901030 CE 47U0F +20% 50.0V 85C 1.000 PC
