REF. DESIGNATOR PART NUMBER PART NAME / DESCRIPTION Q'TY UNIT
Miscellaneous
J173 8044051091 RMGCFMIN 0 OHM +0% 100MI0W 1.000 PC
J202 8044051091 RMGCFMIN 0 OHM +0% 100MI0W 1.000 PC
J206 8044051091 RMGCFMIN 0 OHM +0% 100MI0W 1.000 PC
J207 8044051091 RMGCFMIN 0 OHM +0% 100MI0W 1.000 PC
J210 8044051091 RMGCFMIN 0 OHM +0% 100MI0W 1.000 PC
J211 8044051091 RMGCFMIN 0 OHM +0% 100MI0W 1.000 PC
J212 8044051091 RMGCFMIN 0 OHM +0% 100MI0W 1.000 PC
J213 8044051091 RMGCFMIN 0 OHM +0% 100MI0W 1.000 PC
J214 8044051091 RMGCFMIN 0 OHM +0% 100MI0W 1.000 PC
J215 8044051091 RMGCFMIN 0 OHM +0% 100MI0W 1.000 PC
J222 8044051091 RMGCFMIN 0 OHM +0% 100MI0W 1.000 PC
J223 8044051091 RMGCFMIN 0 OHM +0% 100MI0W 1.000 PC
J230 8044051091 RMGCFMIN 0 OHM +0% 100MI0W 1.000 PC
J231 8044051091 RMGCFMIN 0 OHM +0% 100MI0W 1.000 PC
J232 8044051091 RMGCFMIN 0 OHM +0% 100MI0W 1.000 PC
J233 8044051091 RMGCFMIN 0 OHM +0% 100MI0W 1.000 PC
J234 8044051091 RMGCFMIN 0 OHM +0% 100MI0W 1.000 PC
J235 8044051091 RMGCFMIN 0 OHM +0% 100MI0W 1.000 PC
J236 8044051091 RMGCFMIN 0 OHM +0% 100MI0W 1.000 PC
J237 8044051091 RMGCFMIN 0 OHM +0% 100MI0W 1.000 PC
J238 8044051091 RMGCFMIN 0 OHM +0% 100MI0W 1.000 PC
J239 8044051091 RMGCFMIN 0 OHM +0% 100MI0W 1.000 PC
J243 8044051091 RMGCFMIN 0 OHM +0% 100MI0W 1.000 PC
J244 8044051091 RMGCFMIN 0 OHM +0% 100MI0W 1.000 PC
J245 8044051091 RMGCFMIN 0 OHM +0% 100MI0W 1.000 PC
J246 8044051091 RMGCFMIN 0 OHM +0% 100MI0W 1.000 PC
J247 8044051091 RMGCFMIN 0 OHM +0% 100MI0W 1.000 PC
J248 8044051091 RMGCFMIN 0 OHM +0% 100MI0W 1.000 PC
J288 8044051091 RMGCFMIN 0 OHM +0% 100MI0W 1.000 PC
J294 8044051091 RMGCFMIN 0 OHM +0% 100MI0W 1.000 PC
J4420040300X CNT PLUG 2.5 3P 1.000 PC
CN201 J4305100051X CNT ASSY 7P 450MM SL 2.5MM #24 1.000 PC
CN202 J4305100052X CNT ASSY 3P 620MM SL 2.5MM #24 1.000 PC
CN203 J4305100055X CNT ASSY 9P 400MM SL 2.0MM #26 1.000 PC
CN204 J4305100053X CNT ASSY 4P 100MM SL 2.0MM #26 1.000 PC
CN205 J4305100058X CNT ASSY 4P 360MM SHIELD SL 2.0MM #28 1.000 PC
CN206 J4305100057X CNT ASSY 10P 220MM SHIELD SL 2.0MM #28 1.000 PC
CN207 J4112213801X FPC CABLE 21P 380MM 1.25MM 1.000 PC
CN208 J4112275001X FPC CABLE 27P 500MM 1.25 1.000 PC
CN209 J4305100059X CNT ASSY 8P 500MM SHIELD SL 2.0MM #8 1.000 PC
CN210 J4305100063X CNT ASSY 2P 100MM SL 2.0MM #26 1.000 PC
CP201 J4422212740X FPC PLUG 27P 1.25 1.000 PC
CP202 J4422212140X FPC PLUG 21P 1.25MM ANG GF120-21S-LS 1.000 PC
CP203 J4420030840X CNT PLUG 2.0 ST 8P 1.000 PC
CP204 J4420030540X CNT PLUG 2.0 ST 5P 1.000 PC
JA201 J44303000100 JACK RCA 3P 1.000 PC
JA202 J44311000100 JACK S-VIDEO 1P 1.000 PC
L201 J2616247920X COIL 4.7UH K 1.000 PC
L202 J2616247920X COIL 4.7UH K 1.000 PC
FL201 J2352230020X VFD HNA-16LL15 1.000 PC
FN201 J60600006000 SHIELD FENCE TONE 1.000 PC
W201 J4305100025X LUG WIRE 1P 200MM #18 1.000 PC
X201 J3911030020X RESONATOR ZTA10MTT 1.000 PC
DCR600 KEY PCB
Capacitors
C401 3093924091 CCCFMIN 22N0F +10% -10% 50.0V X7R 1.000 PC
C402 3093924091 CCCFMIN 22N0F +10% -10% 50.0V X7R 1.000 PC
C403 1105933091 CCCFMIN 2N2F +10% -10% 50.0V X7R 1.000 PC
C404 1105933091 CCCFMIN 2N2F +10% -10% 50.0V X7R 1.000 PC
C405 2026729091 CCCFMIN 100N0F +80% -20% 50.0V Y5V 1.000 PC
C406 2026729091 CCCFMIN 100N0F +80% -20% 50.0V Y5V 1.000 PC
C409 1105867091 CCCFMIN 100P0F +5% -5% 50.0V NP0 1.000 PC
C410 1105867091 CCCFMIN 100P0F +5% -5% 50.0V NP0 1.000 PC
DCR600
47
