14
gX-a602 speaker connectIons: brIdged operatIon
Bridged operation provides a single high-power channel for a subwoofer
Minimum speaker impedance: 4 ohms
ConnectthesubwoofertotheRL(+)andRR(–)terminals.NOTE: You can connect two 2-ohm subwoofers in series to maintain the required 4-ohm
impedance for bridged operation.
Subwoofer
