gX-a604 speaker connectIons: 2-channel opera
tIon
Minimum speaker impedance: 4 ohms (each)
Connecttheleftandrightspeakersasshownintheillustrationbelow
.
Speaker
Fuses 20A
Left Speaker
Right Speaker
6
8
Table of Contents
Power Connectors
2
Source Unit
4
Left Speaker
7
Right Speaker
7
Troubleshooting
9
Specifications
11
