JBL GX-A604 - Specifications

26
specificAtions
GX-A604 GX-A602 GX-A3001
Maxpower(15.5V,1kHz,10%THD,
total ch, 2 ohms)
435W 280W
415W(15.5V,50Hz,10%THD,
2 ohms)
Rated power output @ 4 ohms 60Wx4 60Wx2 200Wx1
Bridged power output
(4ohms,1%THD)
170Wx2 170Wx1 N/A
THD+Natratedpower <1% <1% <1%
Signal-to-noise(2V@4ohms) >75dB >75dB >75dB
Effective damping factor (4 ohms) >50 >50 >50
Frequency response (–3 dB) 20Hz–20kHz±1dB 20Hz–20kHz±1dB 10Hz–320Hz
Maximuminputvoltage 20V 20V 20V
Maximuminputsensitivity 200mV 200mV 200mV
Fuse size 20Ax2 25A 20Ax2
Dimensions(HxWxD)
2-1/16"x11-13/16"x8-1/8"
(52mmx300mmx206mm)
2-1/16"x7-13/16"x8-1/8"
(52mmx198mmx206mm)
2-1/16"x11-7/16"x8-1/8"
(52mmx291mmx206mm)
Weight 5.3lb(2.4kg) 3.8lb(1.7kg) 5.3lb(2.4kg)
