Getting Acquainted with the EON208P Powered Mixer

This part of the EON208P system houses the mixing board and power amplier. You will connect all of the

microphones, musical instruments, Bluetooth

audio device, external sound sources (like MP3 or CD players),

in addition to any recording devices or additional speakers like a personal monitor, subwoofer or "Front of

House" feed.

The Basics

The mixing board is actually a very simple device. A "mixing board" brings audio sources "in" (through

the inputs) and routes the signal to the outputs (MASTER VOLUME/SPEAKER OUTPUTS or MONITOR

OUTPUTS). The mixer controls enable the user to affect the tone and/or volume in addition to routing the signal

and adding reverb to individual input sources.

Let's look at the "inputs" rst:

AUDIO INPUTS

All of the inputs will route to the speakers and to the MONITOR OUTPUT SECTION.

MONO MIC/LINE INPUTS

Moving from left to right there are 4 identical input strips comprised of (from top to bottom) a treble control,

bass control, reverb control, reverb on/off button, volume control, mic/line selector and a XLR ¼"

combination connector.

BLUETOOTH INPUT

The EON208P comes equipped with the ability to stream Bluetooth audio.

To connect a Bluetooth device rst press the "Bluetooth Pair" button on the

back of the device. Then select "EON208P" from the source device to

complete the pairing. Once paired, audio can be streamed from the

connected device.
