JBL HLA 4895 User Manual

49
Stadium, Typical
Large Outdoor Stadium
200 m approximate diameter
Large-sized stadium for typical major rock show
Stage Size: 25m x 25m (W x D)
Purpose:
Dimensions:
Setup:
HLA Array Data:
Symmetrical flown systems either side of stage
Subs stacked.
6 x 5 clusters: 30 4895 +18 Subs stacked at stage level
Coverage: 120°H x 45°V each cluster
Trim height: 6 m to Lower Edge
Max SPL @1m: 170 dB SPL
@ rear of venue: 126 dB SPL
Weight: 2864 kg w/o rigging
Requires at least 21 amplifiers per cluster
