JBL Loud+Clear LC-S1000w - Subwoofer Specifications; Thiele and Small Parameters; Sealed Enclosure Volumes; Vented Enclosure Specs

Subwoofer
JBL Consumer Products 250 Crossways Park Drive, Woodbury, NY 11797 8500 Balboa Boulevard, Northridge, CA 91329 1-800-336-4JBL (4525) (USA only) www.jbl.com
©
1999 JBL, Incorporated
JBL is a registered trademark of JBL, Incorporated.
Part No. LCWOOFOM 2/99
RECYCLABLE
LC-S1200w
12–200W
91dB
40Hz–500Hz
5" (127mm)
10-3/4" (273mm)
4 Ohms
3.45 Ohms
27.4Hz
124 Liters
3.18 0.37 0.33
109.2g
2.2mH
1.25 cu. ft. (35.88 Liters) 1.75 cu. ft. (49.54 Liters)
4" (101.6mm)
10-3/4" (273mm)
1.25 cu. ft. (35.88 Liters)
1 cu. ft. (28.31 Liters)
4" (101.6mm) 6" (152.4mm)
LC-S800w
Specifications Recommended Amplifier Power Range 12–100W Sensitivity 89dB Frequency Response 47Hz–2kHz Mounting Depth 4-1/8" (105mm) Cut-out Diameter 7" (178mm) Thiele and Small Parameters Nominal Impedance 4 Ohms Revc 3.47 Ohms Fs 33.27Hz Vas 32.67 Liters Qms 4.67 Qes 0.38 Qts 0.33 Mms 48.6g Levc 2.1mH Sealed-Enclosure Specifications Enclosure Volume .4 cu. ft. (11.32 Liters) Vented-Enclosure Specifications Enclosure Volume .6 cu. ft. (19.96 Liters) Port Diameter 3" (76.2mm) Port Length 10" (254mm) Bandpass-Enclosure Specifications Sealed-Chamber Volume .4 cu. ft. (11.32 Liters) Vented-Chamber Volume .4 cu. ft. (11.32 Liters) Port Diameter 3" (76.2mm) Port Length 7" (177.8mm)
LC-S1000w
12–150W
90dB
40Hz–800Hz
4-1/2" (114mm)
9" (229mm)
4 Ohms
3.52 Ohms
28.5Hz
71 Liters
4.39 0.34 0.32
75.0g
2.0mH
1 cu. ft. (28.31 Liters)
1.5 cu. ft. (42.46 Liters)
3" (76.2mm)
7" (177.8mm)
1 cu. ft. (28.31 Liters)
.7 cu. ft. (19.82 Liters)
4" (101.6mm) 8" (203.2mm)
