Contents
MC-19 Mounting Template ---------------------------------------------------- 1
Contents -------------------------------------------------------------------------- 2
Mounting the Black Box ------------------------------------------------------ 3
Important Notes ----------------------------------------------------------------- 4
Identification of Controls and Functions ------------------------------------ 5
Controls ( In Detail ) ---------------------------------------------------------- 6-8
Station Tuning ------------------------------------------------------------------- 9
Resetting the Black Box ------------------------------------------------------ 10
Trouble Shooting Guide ------------------------------------------------------ 11
Specifications ----------------------------------------------------------------- 11
Poor atmospheric conditions - Try again later in the day
Antenna / lead broken or damaged
INTERFERENCE ON RADIO
P:
Power Supply :
Speaker Impedance:
ower Output 4 x 45 watts
DC + 12V
Negative Ground
4 ohm
T:
Sensitivity :
uning Range 530 ~ 1710KHz(USA)
522 ~ 1620KHz(EUR)
35dB / uV
T:
Sensitivity :
Separation :
uning Range 87.5 ~ 107.9MHz(USA)
87.5 ~ 108MHz(EUR)
10dB / uV
30dB
FM TUNER AM TUNER (OPTION)
AUDIO AMP & GENERAL
DISTORTED AUDIO
Trouble shooting Guide
Specifications
Check loudspeaker wiring
This product contains a biamp. It is important not to connect the front
loudspeaker ground to the rear speaker ground.
Faulty loudspeaker
Distortion at highest volume levels may be normal, as amplifier has reached
maximum power output. Otherwise the power and ground wire might be too
small of a gauge. Use 10amp cable or more.
Reduce the bass effect or switch off the loudness mode
Boat battery and or charging circuit may be faulty
