116
Wiring
Important Notes -------------------------------------------------------------- 3
Installation -------------------------------------------------------------------- 4
Supporting the Unit ---------------------------------------------------------- 5
Identification of Control Functions ---------------------------------------- 6
General Controls ----------------------------------------------------------- 7-9
Operating the Radio -------------------------------------------------------- 10
Operating the CD Player ---------------------------------------------- 11-12
Operating the USB --------------------------------------------------------- 13
AUX, RCA Description ---------------------------------------------------- 13
Precautions and Maintenance --------------------------------------------- 14
Trouble Shooting Guide -------------------- ------------------------------ 15
Specifications --------------------------------------------------------------- 16
Identification -------------------------------------------------------- 2
Contents
Specifications
Operation Voltage ------------------------------ 12 volts DC, Negative Ground
Output Power ----------------------------------- 180 watts maximum
(45wattsx4channels)
Output Impedance ------------------------------ compatible with 4 ~8 ohm speakers
Tuning Range
USAAREA ----------------------------------- FM: 87.5 ~ 107.9MHz. (200KHz step)
AM: 530 ~1710 KHz. (10KHz step)
Sensitivity --------------------------------------- AM: 35 dBu
FM: 10 dBu
FM Stereo Separation -------------------------- 30 dB
CD/USB Frequency Response ----------------- 20 ~20,000 Hz
CD/USB S/N Ratio ----------------------------- 63 dB
CD/USB Channel Separation ------------------ 50 dB
AUX Input Sensitivity ------------------------- 2V (VOLUME STEP 20)
400 and 800mV@10K ohm
EUR AREA ----------------------------------- FM: 87.5 ~ 108MHz. (50KHz step)
AM: 522 ~1620 KHz. (9KHz step)
