System Spec
System Type: Self powered 15", two-way, bass-reflex
Maximum SPL Output: 135 dB (Full Range) peak, 134 dB (Monitor) peak
Frequency Range (-10 dB):
Full Range 45 Hz - 19 kHz
Monitor (vertical orientation) 55 Hz - 19 kHz
Monitor (monitor orientation) 48 Hz - 20 kHz
Frequency Response (±3 dB):
Full Range 54 Hz - 18 kHz
Monitor (vertical orientation) 75 Hz - 18.5 kHz
Monitor (monitor orientation) 60 Hz - 18kHz
Input Connectors: Balanced XLR / 1/4 inch combo jack with XLR loop through
Input Impedance: 20K Ohms (balanced), 10K Ohms (unbalanced)
Signal indicators: Limit : Red LED indicates limiter active condition
Signal: Green LED indicates signal present
EQ: Presets for use in Main and Monitor position
Dynamic Control (Input): dbx Type IV™ limiter circuit
Crossover Modes: DSP controlled. LF: 48 dB/Oct. filter slope High & Low Pass
HF: 36dB/Oct High Pass
Crossover Frequency: 1.8 kHz
Amplifier
Design: Crown® Class D
Power Rating: 1000 W (2 x 500)
Speaker
LF Driver: 1 x JBL 265F-1 380 mm (15 in) Differential Drive® dual voice-coil
and magnetic gap, neodymium woofer
HF Driver: 1 x JBL 2408H 37.5 mm (1.5 in) annular polymer
diaphragm,neodymium compression driver
Coverage Pattern: 90º x 50º nominal
Directivity Index (DI): 10.0 dB
Directivity Factor (Q): 10.0
Enclosure: Asymmetrical, 18 mm, plywood
Suspension/ Mounting: Dual 36 mm pole socket, 8 x M10 Suspension Points and 1 x M10
Pull-Back Point
Transport: Integrated handle with backing cup
Finish: Obsidian DuraFlex™ finish
Grille: Powder coated, Obsidian, 16 gauge perforated steel with
acoustically transparent black cloth backing.
Input Connectors: Balanced XLR / 1/4 inch combo jack with XLR loop through
Dimensions (H x W x D): 660 mm x 429 mm x 414 mm (26 in x 16.9 in x 16.3 in)
Net Weight: 19.7 kg (43.5 lb)
Gross Weight: 24.2 kg (53.5 lb)
PRX615M
14
