JBL PX600.2 - Page 11

ELC-00-00137 CAPACITOR
ELECTROLYTIC "SG"
10/25V 1C07
ELC-00-00127 CAPACITOR
ELECTROLYTIC "SG"
22/16V 4C101,102,201,202
ELC-00-00130 CAPACITOR
ELECTROLYTIC "SG"
47/16V 2C03,08
ELC-00-00159 CAPACITOR
ELECTROLYTIC "SG"
47/50V 1C62
ELC-00-00523 CAPACITOR
ELECTROLYTIC "SG"
100/16V 6C01,02,05,142,171,271
ELC-00-00254 CAPACITOR
ELECTROLYTIC "SXE"
100/25V 1C09
MYC-00-00184 CAPACITOR
MYLAR 5% 100V
102 J 1C17
MYC-00-00186 CAPACITOR
MYLAR 5% 100V
222 J 1C16
MYC-00-00194 CAPACITOR
MYLAR 5% 100V
473 J 2C135,235
MYC-00-00175 CAPACITOR
MYLAR 5% 100V
823 J 8C110,111,113,114,210,211,213,214
MYC-00-00183 CAPACITOR
MYLAR 5% 100V
104 J 3C26,161,261
MYC-00-00085 CAPACITOR
MYLAR 5% 63V "TL"
105 J 2C13,29
CEC-00-00106 CAPACITOR
CERAMIC DISK 50V"NPO"
5pF 1C208
CEC-00-00079 CAPACITOR
CERAMIC DISK 50V"NPO"
12pF 1C108
CEC-00-00090 CAPACITOR
CERAMIC DISK 50V"NPO"
22pF 7C61,103,104,170,203,204,270
CEC-00-00103 CAPACITOR
CERAMIC DISK 50V"NPO"
47pF 4C109,112,209,212
CEC-00-00073 CAPACITOR
CERAMIC DISK 50V"NPO"
100pF 10
C105,132,134,141,144,205,232,234,241,244
CEC-00-00101 CAPACITOR
CERAMIC DISK 50V"NPO"
470pF 2C173,273
CEO-00-00075 CAPACITOR
CERAMIC DISK 50V"NPO"
103pF 1C18
CEC-00-00102 CAPACITOR
CERAMIC DISK 50V
473pF 11C23,24,301,302,303,304,401,402,403,404
C808
CEC-00-00074 CAPACITOR
CERAMIC DISK 50V"NPO"
102pF 2C100,200
CEC-00-00076 CAPACITOR
CERAMIC DISK 50V
104pF 6C04,06,14,15,25,39
ICO-00-00022 I.C P.W.M TL494CN
1
U01
ICO-00-00109 I.C QUAD OPAMP,DIP-14 NJM2058D
4
U101,103,104,105
ICO-00-00111 I.C DUAL OP AMP NJM2068D
1
U102
ICO-00-00095 I.C COMPARATOR DIP08 KIA393P
1
U801
TRS-00-00111 TRANSISTOR SMALL SIGNAL NPN KTC3200GR
2
Q130,230
TRS-00-00089 TRANSISTOR AUDIO DRIVE PNP
KSA1220A-Y /KTB631
8
Q133,144,145,146,233,244,245,246
TRS-00-00106 TRANSISTOR AUDIO DRIVE NPN
KSC2690A-Y /KTB600
8
Q134,135,136,143,234,235,236,243
TRS-00-00188 TRANSISTOR AUDIO POWER PNP TIP35C
6
Q137,138,139,237,238,239
TRS-00-00207 TRANSISTOR AUDIO POWER NPN TIP36C
6
Q147,148,149,247,248,249
FET-00-00034
F.E.T N-CH POWER FET,"TO-220"
FQP50N06
12
Q07,08,09,10,11,12,17,18,19,20
Q21,22
DIO-00-00048 DIODE RECTIFIER 1N5404
1
D07
DIO-00-00152 DIODE FAST RECOVERY YG225D2
4
D05,06,11,12
DIO-00-00243 LED 3 PHI BLUE LED HL-304H1BC2
1
LED02
DIO-00-00277 LED 3 PHI RED LED HNRD-3401L
2
LED01,801
RES-00-00844 RESISTOR MOR-S 2WJ 100 OHM
1
R30
RES-00-01044 RESISTOR
MOR-S 2WJ "FORMING TYPE 15mm"
680 OHM
4
R165,191,265,291
RES-00-01079 RESISTOR
MOR-S 2WJ "FORMING TYPE 15mm"
2.2K OHM
2
R40,41
RES-00-00952 RESISTOR
WIRE WOUND 5WJ "FORMING 25m
m
0.1 OHM
12
R154,155,156,157,158,159,254,255,256,257
R258,259
THS-00-00013 THERMISTOR 50K FTD5-350
1
TH01
VOL-00-00114 VOLUME V12L5(9X5)G(PH2D)N17KC 3B20KX2
1
VR101
VOL-00-00281 VOLUME
V12L5(9X5)G(8R)(PH2D)N15KC
15C50KX8
1
VR102
ELC-00-00168 CAPACITOR ELECTROLYTIC "SG" "10X22" 220/63V
2
C55,65
ELC-00-00133 CAPACITOR ELECTROLYTIC "SG" 330/16V
2
C191,291
ELC-00-00169 CAPACITOR ELECTROLYTIC "SG" "12X25" 470/63V
2
C19,20
ELC-00-00092 CAPACITOR ELECTROLYTIC "RX" "16X25" 2200/25V
4
C10,11,32,33
ELC-00-00039 CAPACITOR ELECTROLYTIC "HC" "35x25" 4700/75V
2
C27,28
JUP-00-00003 BAR JUMPER NI-PLATE 35m/m
4
T12,13,14,15
SWI-00-00022 SWITCH SLIDE SWITCH "6mm" JSS-2208A
2
SW03,05
SWI-00-00035 SWITCH SLIDE SWITCH "6mm" JSS-4319A
1
SW01
JAC-00-00043 RCA JACK GOLD PLATED DJB-554A
1
RCA01
HOD-00-00006 FUSE HOLDER PCB TYPE JSF-08031
2
FH01,02
TER-00-00217 POWER TERMINAL GOLD PLATED KTD-9216A
1
TER2
TER-00-00218 POWER TERMINAL GOLD PLATED KTD-9218A
1
TER1
