JBL PX600.2 - Table of Contents; Specifications

CONTENTS
Specifications………………………….…………………..……1
Features…………………………………………………………2
Test Conditions And Notes……………………………………2
Controls/connections…………………………………..………3
Mounting…………………………………………….…..………3
Applications………………………………………..……………4
Typical System Configuration…………………………………5
Troubleshooting……………………………………….……..…6
PCB drawings……………………………………..……………7
Parts List………………………………………………..………9
Block Diagrams……………………………………….………12
Semiconductor Pinouts………………………………………13
Exploded view…………………………………………………16
Schematics……………………………………………….……17
Packing…………………………………………………………26
SPECIFICATIONS
Power Output, 4 Ohms 150W x 2
Power Output, 2 Ohms 300W x 2
Power Output, .Bridged, 4 Ohms 600W x 1
MIN. Speaker Impedance 2 ohm
Frequency Response ..... 10Hz~45KHz, ±1dB
Input Sensitivity (RCA type) 250mV~6V
THD + Noise (4 Ohms) ..... 0.04%
Signal-to-Noise 95 dB
Maximum Current Draw 78A
Fuse Replacement 30Ax2
External Dimensions
Length 12 ¼” (312mm)
Width 17” (432mm)
Depth 2 9/16” (66mm)
JBL continually strives to improve its products. New materials, production methods and design refinements are introduced into existing
models without notice as a routine expression of our design philosophy. For this reason, Power Series Multichannel Automotive
Amplifiers may differ in some respects from their published specifications and descriptions, but will always equal or exceed the original
specifications unless otherwise stated.
Power Amplifier
PX600.2
