Basic Operation
SDP-5
2-19
DOLBY D STATUS
•Provides information about Dolby Digital input sources.
• Features L, C, R, SL, SR, and SUB level meters (2-23).
Parameter Possible Settings
INPUT The selected input
MODE The activated listening mode
CHANNELS 3/2.1, 3/2, 3/1, 2/2, 2/1, 2/0, 1/0
BIT RATE 32 to 640kbps
EX ENCODING ON, OFF
SAMPLE RATE 48kHz
2.0 ENCODING MATRIX, NONE
DIALOG OFFSET -27 to +4dB
MIX ROOM SMALL, LARGE
CENTER MIX LVL -3.0dB, -4.5dB, -6.0dB
SURR MIX LVL +0.0dB, -3.0dB, -6.0dB
STATUS menu parameter descriptions begin on page 2-22.
2CH STATUS
•Provides information about 2-channel input sources.
• Features L and R level meters (2-23).
Parameter Possible Settings
INPUT The selected input
MODE The activated listening mode
INPUT TYPE ANLG, PCM
SAMPLE RATE 44.1kHz, 48kHz, 88.2kHz, 96kHz
STATUS menu parameter descriptions begin on page 2-22.
