Basic Operation
JBL Synthesis
2-20
dts(-ES) STATUS
•Provides information about dts(-ES) input sources.
• Features L, C, R, SL, SR, SB, and SUB level meters (2-23). The
SB level meter appears when a 6.1-channel input source is
present, or when a 5.1-channel input source is present and the
ES DECODING parameter (5-30) is set to ON.
Parameter Possible Settings
INPUT The selected input
MODE The activated listening mode
CHANNELS 3/3.1, 3/2.1
BIT RATE 754.5 to 1509.7kbps
ES ENCODING DISCRETE, MATRIX, OFF
WORD LENGTH 16bits, 20bits, 24bits
SAMPLE RATE 44.1kHz, 48kHz, 88.2kHz, 96kHz
STATUS menu parameter descriptions begin on page 2-22.
5.1a BYPASS STATUS
•Provides information about 5.1-channel analog input sources.
Parameter Possible Settings
INPUT The selected input
MODE 5.1a BYPASS
INPUT TYPE BYPASS
STATUS menu parameter descriptions begin on page 2-22.
