SETUP
JBL Synthesis
3-50
ON-SCREEN DISPLAY SETUP
Selecting the DISPLAY SETUP menu ON-SCREEN DISPLAY option
opens the ON-SCREEN DISPLAY menu shown above, which can be
used to customize the on-screen display.
Default Possible
Parameter Setting Settings
STATUS 2 SECONDS ALWAYS ON, 2 SECONDS,
ALWAYS OFF
POSITION TOP TOP, CENTER, BOTTOM
FORMAT NTSC SECAM, PAL, NTSC
BACKGROUND ON ON, OFF
REMOTE STATE ON ON, OFF
ON-SCREEN DISPLAY

DISPLAYS

SETUP
STATUS ALWAYS ON, 2 SECONDS, ALWAYS OFF
Activates and deactivates the on-screen display sent to the Main
Zone video output connector. When set to ALWAYS ON, the
on-screen display remains on at all times. When set to 2 SECONDS,
the on-screen display appears for 2 seconds whenever the input
source changes or the SDP-5 receives a command. When set to
ALWAYS OFF, the on-screen display remains off at all times. It will
not reappear until the ON-SCREEN DISPLAY menu STATUS
parameter is set to ALWAYS ON or 2 SECONDS.
Note:
When the ON-SCREEN DISPLAY menu STATUS
parameter is set to ALWAYS OFF, the on-screen
display immediately disappears. Press the remote
control OSD button or use the front panel display as
a guide to reset the parameter to ALWAYS ON or 2
SECONDS.
STATUS

ON-SCREEN DISPLAY

DISPLAYS

SETUP
MAIN MENU
MODE ADJUST
AUDIO CONTROLS
SETUP
SETUP

SETUP
INPUTS
SPEAKERS
REAR PANEL CONFIG
DISPLAYS
VOLUME CONTROLS
TRIGGER
LOCK OPTIONS
DISPLAYS
DISPLAY SETUP
ON-SCREEN DISPLAY
FRONT PANEL DISPLAY
A/V SYNC DELAY OFF
CUSTOM NAME OFF
EDIT CUSTOM NAME

ON-SCREEN DISPLAY
ON-SCREEN DISPLAY
STATUS 2 SECONDS
POSITION TOP
FORMAT NTSC
BACKGROUND ON
REMOTE STATE ON

STATUS 2 SECONDS
ALWAYS ON
2 SECONDS
ALWAYS OFF
