Model LF Mid HF Horn Rated System Freq Range Crossover Nominal Dispersion Weight Shape Dimensions
Driver Driver Power* Impedance (-10 dB) Frequency Sensitivity** (H X V)
SR4702X 2206H -- 2426H OASR 600 8 42Hz-20kHz 1.3 kHz 95dB 85º x 85º 29 kg Multi-angle 648 x 403 x 356
64 lbs Monitor 25.5 x 15.9 x 14
SR4715X 2226H -- -- -- 1200 4 35Hz-300Hz 80 - 100 Hz 100dB -- 47.2 kg Rectangular 1067 x 616 x 435
(x2) recommended 104 lbs 42 x 24.3 x 17.1
SR4718X 2241G -- -- -- 600 4 38Hz-300Hz 80 – 100 Hz 98dB -- 39.9 kg Rectangular 616 x 613 x 610 mm
recommended 88 lbs 24.3 x 24.1 x 24 in
SR4719X 2241H -- -- -- 1200 4 30Hz-300Hz 80 – 100 Hz 101dB -- 85.3 kg Rectangular 765 x 1219 x 616
(x2) recommended 188 lbs 30.1 x 48 x 24.3
SR4722X 2206H -- 2417H OASR 600 8 42Hz-18kHz 1.2 kHz 95dB 85º x 85º 27.2 kg Trapezoidal 686 x 486 x 333
SR4722X/F 60 lbs 27 x 19.1 x 13.1
SR4725X 2226H -- 2426H 2370A 600 8 35Hz-18kHz 1.1 kHz 98dB 90º X 40º 37.2 kg Trapezoidal 718 x 616 x 435
SR4725X/F 82 lbs 28.3 x 24.3 x 17.1
SR4726X 2226H -- 2447H 2381 600 8 35Hz-20kHz 1.1 kHz 97dB 90º X 50º 48.5 kg Trapezoidal 883 x 616 x 435
SR4726X/F 2383 60º X 50º 107 lbs 34.8 x 24.3 x 17.1
SR4731X 2206H -- 2447H 2381 1200 4 39Hz-20kHz 1.2 kHz 98dB 90º X 50º 59.9 kg Trapezoidal 1067 x 616 x 435
SR4731X/F (x2) 2383 60º X 50º 132 lbs 42 x 24.3 x 17.1
SR4732X 2206H 2447H 2404H 2381 1200 4 39Hz-21kHz 1.2 kHz, 98dB 90º X 50º 62.1 kg Trapezoidal 1067 x 616 x 435
SR4732X/F (x2) 6 kHz 137 lbs 42 x 24.3 x 17.1
SR4733X 2226H -- 2447H 2381 1200 4 37Hz-20kHz 1.2 kHz 100dB 90º X 50º 65.8 kg Trapezoidal 1219 x 616 x 435
SR4733X/F (x2) 2383 60º X 50º 145 lbs 48 x 24.3 x 17.1
SR4735X 2226H M209-8A 2426H MH1 600 8 36Hz-20kHz 340 Hz and 97dB 70º X 50º 50.8 kg Trapezoidal 946 x 616 x 479
SR4735X/F 1.6 kHz 112 lbs 37.3 x 24.3 x 18.9
* IEC filtered random noise with a 6 dB crest factor
**1W@1m (2.83V for 8ohms, 2.00V for 4ohms, ave'd 500Hz-5kHz)
Specifications subject to change without notice
SPECIFICATIONS
DuraFlex
The SR-X loudspeaker system is finished in JBL's DuraFlex™. DuraFlex is tough and inherently flexible and it is
extremely resistant to knocks, scratches and scuffs. The DuraFlex finish on your SR-X speakers is actually much
tougher than the plywood to which it is applied. Note: SR-X enclosures are not paintable. In the event that
cosmetic damage occurs to your speakers, a DuraFlex touch-up kit (PN 16677) is available from JBL.
Recommended Power
The following table shows the recommended amplifier power for SR-X models.
1. Full-range / Parallel: Is the amplifier power required to optimally drive this speaker system when used in full-
range (passive) mode. In the case of dual-driver subwoofer models, this is the power required to drive both
transducers at the same time.
2. HF: Is the amplifier power required to optimally drive the high-frequency section of this speaker system when
used in bi-amp mode.
3. LF: Is the amplifier power required to optimally drive the low-frequency section of this speaker system when
used in bi-amp mode.
4. Discrete: Is the amplifier power required to optimally drive an individual transducer in a dual transducer
subwoofer.
5. ±1 or ±2 Pass-Thru: This allows for the convenience of a single conductor cable from the amplifier rack to the
speakers stack, this configuration supplies separate amplifier power to the subwoofer (ie ±2) and to the
mid-high speaker (ie 1 Pass-Thru).
Model Full-Range / Parallel (1) HF (2) LF (3) / Discrete (4)
SR4702X 600 to 1,200W@8Ω 100 to 200W@8Ω 600 to 1,200W@8Ω
SR4715X 1,200 to 2,400W@4Ω n/a 600 to 1,200W@8Ω x2
SR4718X 600 to 1,200W@4Ω n/a n/a
SR4719X 1,200 to 2,400W@4Ω n/a 600 to 1,200W@8Ω x2
SR4722X 600 to 1,200W@8Ω 60 to 120W@8Ω 600 to 1,200W@8Ω
SR4725X 600 to 1,200W@8Ω 100 to 200W@8Ω 600 to 1,200W@8Ω
SR4726X 600 to 1,200W@8Ω 150 to 300W@16Ω 600 to 1,200W@8Ω
SR4731X 1,200 to 2,400W@4Ω 150 to 300W@16Ω 1,200 to 2,400W@4Ω
SR4732X 1,200 to 2,400W@4Ω 150 to 300W@16Ω 1,200 to 2,400W@4Ω
SR4733X 1,200 to 2,400W@4Ω 150 to 300W@16Ω 1,200 to 2,400W@4Ω
SR4735X 600 to 1,200W@8Ω 100 to 200W@8Ω 600 to 1,200W@8Ω
7
