JBL SR-X Series User Manual

CABLE AND CONNECTIONS
Passive Systems & Subs (Parallel Mode)
Bi-Amp Systems & Subs (Discrete Mode)
Wire Gauges
Each connector panel incorporates two Neutrik® Speakon® connectors. The second connector facilitates the
ability to "loop through" to other SR-X speakers in the system. The diagrams below detail the cable-side
connections.
Selection of the appropriate wire gauge is important to system operation. A cable that is too light will result in
amplifier power being wasted due to the series resistance of the cable and in loss of low-frequency performance
due to degraded damping factor.
2-
2
+
1
+
1-
+1
-1
2-
2
+
1
+
1-
+2
-2
+1
-1
Wire Gauge Chart for 0.5 dB Loss
20
15
10
5
5
1.5
50
15
100
30
150
46
200
61
250
76
300
91
Length of Run (ft.) / (m)
Wire Size (AWG)
16 Ohm Load
8 Ohm Load
4 Ohm Load
.52
1.65
5.26
16.77
mm
2
8
