SRX828SP, SRX818SP BACK PANEL
OUTIN
CH
2
CH
1
OUT
NETWORK
LINK
MASTER LEVEL
BACK
POWER
DATA
IN
A HARMAN INTERNATIONAL COMPANY
DESIGNED AND ENGINEERED IN THE USA
MADE IN MEXICO
SERIAL NO. JBL PROFESSIONAL NORTHRIDGE, CA USA
MAIN MENU
PRESET
AUTO DIM
AUTO SLEEP
METERS
2 MAIN
OFF
ON
Power Button
CH1 Direct Out
CH2 Direct Out
CH1 Input
CH2 Input
Locking IEC Inlet
Power LED
LCD Screen
Master
Encoder
Back Button
Ethercon Connector
Data LED
Link LED
