one. Speaker Placement
two. Speaker Connections
Connection Tips
– +– +
– + – +
Speaker Outputs
RIGHT LEFT
RIGHT LEFT
Speakers and electronics ter-
minals have corresponding (+)
and (–) terminals. It is impor-
tant to connect both speakers
identically: (+) on the speaker
to (+) on the amplifier and
(–) on the speaker to (–)
on the amplifier. Wiring “out
of phase” results in thin
sound, weak bass and a poor
stereo image.
TLX105, TLX121, TLX151
TLX171, TLX181
Tweeters should be at
ear level.
Tweeters should be at
ear level.
