INTRODUCTION TO THE VRX918S
The VRX918S is a compact, single, 18" direct radiating subwoofer intended for use in suspended arrays or
ground-supported applications. The suspension system is designed for full compatibility with the VRX932LA-1
line-array speaker system and the VRX-AF array frame.
NOTE:
The VRX918S-WH is designed for fixed installation situations where white loudspeakers are required to match
existing decor. White versions therefore do not have handles, feet or pole mount features.
DIMENSIONAL DRAWINGS FOR VRX918S
749
(29.5)
254
(10.0)
597
(23.5)
508
(20.0)
8
(0.3)
457
(18.0)
235
(9.25)
546
(21.5)
464
(18.25)
298
(11.75)
60
(2.37)
44
(1.75)
79
(3.13)
38
(1.5)
489
(19.25)
610
(24.0)
406
(16.0)
51
(2.0)
508
(20.0)
45
(1.8)
56
(2.2)
Dimensions in mm (inches)
8
